NFS root でブート

玄柴(KURO-SHEEVA)
以前 SheevaPlug で実施した NFS root で bootを玄柴でも試してみる。

起動


         __  __                      _ _
        |  \/  | __ _ _ ____   _____| | |
        | |\/| |/ _` | '__\ \ / / _ \ | |
        | |  | | (_| | |   \ V /  __/ | |
        |_|  |_|\__,_|_|    \_/ \___|_|_|
 _   _     ____              _
| | | |   | __ )  ___   ___ | |_
| | | |___|  _ \ / _ \ / _ \| __|
| |_| |___| |_) | (_) | (_) | |_
 \___/    |____/ \___/ \___/ \__|
 ** MARVELL BOARD: SHEEVA PLUG LE

U-Boot 1.1.4 (Sep  7 2009 - 20:21:09) Marvell version: 3.4.16

U-Boot code: 00600000 -> 0067FFF0  BSS: -> 006CEE60

Soc: 88F6281 A0 (DDR2)
CPU running @ 1200Mhz L2 running @ 400Mhz
SysClock = 400Mhz , TClock = 200Mhz

DRAM CAS Latency = 5 tRP = 5 tRAS = 18 tRCD=6
DRAM CS[0] base 0x00000000   size 256MB
DRAM CS[1] base 0x10000000   size 256MB
DRAM Total size 512MB  16bit width
Flash:  0 kB
Addresses 8M - 0M are saved for the U-Boot usage.
Mem malloc Initialization (8M - 7M): Done
NAND:512 MB

CPU : Marvell Feroceon (Rev 1)

Streaming disabled
Write allocate disabled


USB 0: host mode
PEX 0: interface detected no Link.
Net:   egiga0 [PRIME], egiga1
Hit any key to stop autoboot:  0
Marvell>>
カウントダウンが終わる前にキーを押して、U-Boot のプロンプトに入る。
Hit any key と言われているので、押すのはもちろん ANY キー（笑

環境変数の確認

Marvell>> printenv
baudrate=115200
loads_echo=0
rootpath=/mnt/ARM_FS/
netmask=255.255.0.0
CASset=min
MALLOC_len=1
ethprime=egiga0
bootargs_root=root=/dev/mtdblock2 ro
ethmtu=1500
usb0Mode=host
nandEcc=1bit
ethact=egiga0
serverip=10.10.0.2
ipaddr=10.10.0.1
cesvcid=ULULULULULULPPULULULULULDA
bootargs_end=:::DB88FXX81:eth0:none
image_name=uImage
standalone=fsload 0x2000000 $(image_name);setenv bootargs $(console) root=/dev/mtdblock0 rw ip=$(ipaddr):$(serverip)$(bootargs_end) $(mvPhoneConfig); bootm 0x2000000;
mvPhoneConfig=mv_phone_config=dev0:fxs,dev1:fxs
mvNetConfig=mv_net_config=(00:11:88:0f:62:81,0:1:2:3),mtu=1500
yuk_ethaddr=00:00:00:EE:51:81
netretry=no
rcvrip=169.254.100.100
loadaddr=0x02000000
autoload=no
run_diag=no
bootargs=console=ttyS0,115200 mtdparts=nand_mtd:0x400000@0x100000(uImage),0x1fb00000@0x500000(rootfs) rw root=/dev/mtdblock1 rw ip=10.4.50.4:10.4.50.5:10.4.50.5:255.255.255.0:DB88FXX81:eth0:none
bootcmd=nand read.e 0x800000 0x100000 0x400000; bootm 0x800000
ethaddr=00:50:43:01:44:96
stdin=serial
stdout=serial
stderr=serial
console=console=ttyS0,115200 mtdparts=nand_mtd:0x100000@0(uboot)ro,0x0@0x100000(uImage),0x1ff00000@0x100000(rootfs)rw
mainlineLinux=no
enaMonExt=no
enaCpuStream=no
enaWrAllo=no
pexMode=RC
disL2Cache=no
setL2CacheWT=yes
disL2Prefetch=yes
enaICPref=yes
enaDCPref=yes
sata_dma_mode=yes
netbsd_en=no
vxworks_en=no
bootdelay=3
disaMvPnp=no
enaAutoRecovery=yes

Environment size: 1393/131068 bytes
Marvell>>

bootargs の変更

Marvell>> set serverip 192.168.2.38
Marvell>> set ipaddr 192.168.2.89
Marvell>> set bootargs console=ttyS0,115200 mtdparts=nand_mtd:0x400000@0x100000(uImage),0x1fb00000@0x500000(rootfs) rw root=/dev/nfs rw nfsroot=$(serverip):/srv/nfs/rootfsv1.0 ip=$(ipaddr):$(serverip)$(bootargs_end)
Marvell>> saveenv
Saving Environment to NAND...
Erasing Nand...Writing to Nand... done
Marvell>>

reboot

Marvell>> reset

         __  __                      _ _
        |  \/  | __ _ _ ____   _____| | |
        | |\/| |/ _` | '__\ \ / / _ \ | |
        | |  | | (_| | |   \ V /  __/ | |
        |_|  |_|\__,_|_|    \_/ \___|_|_|
 _   _     ____              _
| | | |   | __ )  ___   ___ | |_
| | | |___|  _ \ / _ \ / _ \| __|
| |_| |___| |_) | (_) | (_) | |_
 \___/    |____/ \___/ \___/ \__|
 ** MARVELL BOARD: SHEEVA PLUG LE

U-Boot 1.1.4 (Sep  7 2009 - 20:21:09) Marvell version: 3.4.16

U-Boot code: 00600000 -> 0067FFF0  BSS: -> 006CEE60

Soc: 88F6281 A0 (DDR2)
CPU running @ 1200Mhz L2 running @ 400Mhz
SysClock = 400Mhz , TClock = 200Mhz

DRAM CAS Latency = 5 tRP = 5 tRAS = 18 tRCD=6
DRAM CS[0] base 0x00000000   size 256MB
DRAM CS[1] base 0x10000000   size 256MB
DRAM Total size 512MB  16bit width
Flash:  0 kB
Addresses 8M - 0M are saved for the U-Boot usage.
Mem malloc Initialization (8M - 7M): Done
NAND:512 MB

CPU : Marvell Feroceon (Rev 1)

Streaming disabled
Write allocate disabled


USB 0: host mode
PEX 0: interface detected no Link.
Net:   egiga0 [PRIME], egiga1
Hit any key to stop autoboot:  0

NAND read: device 0 offset 0x100000, size 0x400000

Reading data from 0x4ff800 -- 100% complete.
 4194304 bytes read: OK
## Booting image at 00800000 ...
   Image Name:   Linux-2.6.22.18
   Created:      2009-03-19   9:18:16 UTC
   Image Type:   ARM Linux Kernel Image (uncompressed)
   Data Size:    2106696 Bytes =  2 MB
   Load Address: 00008000
   Entry Point:  00008000
   Verifying Checksum ... OK
OK

Starting kernel ...

Uncompressing Linux.................................................................................................................................... done, booting the kernel.
Linux version 2.6.22.18 (dhaval@devbox) (gcc version 4.2.1) #1 Thu Mar 19 14:46:22 IST 2009
CPU: ARM926EJ-S [56251311] revision 1 (ARMv5TE), cr=00053177
Machine: Feroceon-KW
Using UBoot passing parameters structure
Memory policy: ECC disabled, Data cache writeback
CPU0: D VIVT write-back cache
CPU0: I cache: 16384 bytes, associativity 4, 32 byte lines, 128 sets
CPU0: D cache: 16384 bytes, associativity 4, 32 byte lines, 128 sets
Built 1 zonelists.  Total pages: 130048
Kernel command line: console=ttyS0,115200 mtdparts=nand_mtd:0x400000@0x100000(uImage),0x1fb00000@0x500000(rootfs) rw root=/dev/nfs rw nfsroot=192.168.2.38:/srv/nfs/rootfsv1.0 ip=192.168.2.89:192.168.2.38:::DB88FXX81:eth0:none
PID hash table entries: 2048 (order: 11, 8192 bytes)
Console: colour dummy device 80x30
Dentry cache hash table entries: 65536 (order: 6, 262144 bytes)
Inode-cache hash table entries: 32768 (order: 5, 131072 bytes)
Memory: 256MB 256MB 0MB 0MB = 512MB total
Memory: 515456KB available (3864K code, 257K data, 104K init)
Mount-cache hash table entries: 512
CPU: Testing write buffer coherency: ok
NET: Registered protocol family 16

CPU Interface
-------------
SDRAM_CS0 ....base 00000000, size 256MB
SDRAM_CS1 ....base 10000000, size 256MB
SDRAM_CS2 ....disable
SDRAM_CS3 ....disable
PEX0_MEM ....base e8000000, size 128MB
PEX0_IO ....base f2000000, size   1MB
INTER_REGS ....base f1000000, size   1MB
NFLASH_CS ....base fa000000, size   2MB
SPI_CS ....base f4000000, size  16MB
BOOT_ROM_CS ....no such
DEV_BOOTCS ....no such
CRYPT_ENG ....base f0000000, size   2MB

  Marvell Development Board (LSP Version KW_LSP_4.2.7_patch2)-- SHEEVA PLUG  Soc: 88F6281 A0 LE

 Detected Tclk 200000000 and SysClk 400000000
MV Buttons Device Load
Marvell USB EHCI Host controller #0: c08b8600
PEX0 interface detected no Link.
PCI: bus0: Fast back to back transfers enabled
SCSI subsystem initialized
usbcore: registered new interface driver usbfs
usbcore: registered new interface driver hub
usbcore: registered new device driver usb
NET: Registered protocol family 2
Time: kw_clocksource clocksource has been installed.
IP route cache hash table entries: 16384 (order: 4, 65536 bytes)
TCP established hash table entries: 65536 (order: 7, 524288 bytes)
TCP bind hash table entries: 65536 (order: 6, 262144 bytes)
TCP: Hash tables configured (established 65536 bind 65536)
TCP reno registered
RTC registered
Use the XOR engines (acceleration) for enhancing the following functions:
  o RAID 5 Xor calculation
  o kernel memcpy
  o kenrel memzero
Number of XOR engines to use: 4
cesadev_init(c000c894)
mvCesaInit: sessions=640, queue=64, pSram=f0000000
Warning: TS unit is powered off.
MV Buttons Driver Load
NTFS driver 2.1.28 [Flags: R/O].
JFFS2 version 2.2. (NAND) 誕 ・001-2006 Red Hat, Inc.
io scheduler noop registered
io scheduler anticipatory registered (default)
Serial: 8250/16550 driver $Revision: 1.90 $ 4 ports, IRQ sharing disabled
serial8250.0: ttyS0 at MMIO 0xf1012000 (irq = 33) is a 16550A
serial8250.0: ttyS1 at MMIO 0xf1012100 (irq = 34) is a 16550A
Loading Marvell Ethernet Driver:
  o Cached descriptors in DRAM
  o DRAM SW cache-coherency
  o Single RX Queue support - ETH_DEF_RXQ=0
  o Single TX Queue support - ETH_DEF_TXQ=0
  o TCP segmentation offload enabled
  o Receive checksum offload enabled
  o Transmit checksum offload enabled
  o Network Fast Processing (Routing) supported
  o Driver ERROR statistics enabled
  o Driver INFO statistics enabled
  o Proc tool API enabled
  o Rx descripors: q0=128
  o Tx descripors: q0=532
  o Loading network interface(s):
    o eth0, ifindex = 1, GbE port = 0
    o eth1, ifindex = 2, GbE port = 1

mvFpRuleDb (dfd00000): 16384 entries, 65536 bytes
Intel(R) PRO/1000 Network Driver - version 7.3.20-k2-NAPI
Copyright (c) 1999-2006 Intel Corporation.
e100: Intel(R) PRO/100 Network Driver, 3.5.17-k4-NAPI
e100: Copyright(c) 1999-2006 Intel Corporation
Integrated Sata device found
scsi0 : Marvell SCSI to SATA adapter
scsi1 : Marvell SCSI to SATA adapter
NFTL driver: nftlcore.c $Revision: 1.98 $, nftlmount.c $Revision: 1.41 $
NAND device: Manufacturer ID: 0xec, Chip ID: 0xdc (Samsung NAND 512MiB 3,3V 8-bit)
Scanning device for bad blocks
2 cmdlinepart partitions found on MTD device nand_mtd
Using command line partition definition
Creating 2 MTD partitions on "nand_mtd":
0x00100000-0x00500000 : "uImage"
0x00500000-0x20000000 : "rootfs"
ehci_marvell ehci_marvell.70059: Marvell Orion EHCI
ehci_marvell ehci_marvell.70059: new USB bus registered, assigned bus number 1
ehci_marvell ehci_marvell.70059: irq 19, io base 0xf1050100
ehci_marvell ehci_marvell.70059: USB 2.0 started, EHCI 1.00, driver 10 Dec 2004
usb usb1: configuration #1 chosen from 1 choice
hub 1-0:1.0: USB hub found
hub 1-0:1.0: 1 port detected
USB Universal Host Controller Interface driver v3.0
usbcore: registered new interface driver usblp
drivers/usb/class/usblp.c: v0.13: USB Printer Device Class driver
Initializing USB Mass Storage driver...
usbcore: registered new interface driver usb-storage
USB Mass Storage support registered.
mice: PS/2 mouse device common for all mice
i2c /dev entries driver
Linux telephony interface: v1.00
Marvell Telephony Driver:
mvBoardVoiceAssembleModeGet: TDM not supported(boardId=0x9)
assembly=-1,irq=-1
mp_check_config: Error, invalid voice assembley mode
md: linear personality registered for level -1
md: raid0 personality registered for level 0
md: raid1 personality registered for level 1
raid6: int32x1     97 MB/s
raid6: int32x2    114 MB/s
raid6: int32x4    122 MB/s
raid6: int32x8    110 MB/s
raid6: using algorithm int32x4 (122 MB/s)
md: raid6 personality registered for level 6
md: raid5 personality registered for level 5
md: raid4 personality registered for level 4
raid5: measuring checksumming speed
   arm4regs  :  1084.000 MB/sec
   8regs     :   754.800 MB/sec
   32regs    :   899.600 MB/sec
raid5: using function: arm4regs (1084.000 MB/sec)
device-mapper: ioctl: 4.11.0-ioctl (2006-10-12) initialised: dm-devel@redhat.com
dm_crypt using the OCF package.
sdhci: Secure Digital Host Controller Interface driver
sdhci: Copyright(c) Pierre Ossman
mvsdmmc: irq =28 start f1090000
mvsdmmc: no IRQ detect
usbcore: registered new interface driver usbhid
drivers/hid/usbhid/hid-core.c: v2.6:USB HID core driver
Advanced Linux Sound Architecture Driver Version 1.0.14 (Thu May 31 09:03:25 2007 UTC).
mvCLAudioCodecRegGet: Error while reading register!
mvCLAudioCodecInit: Error - Invalid Cirrus Logic chip/rev ID!
Error - Cannot initialize audio decoder.at address =0xff<6>ALSA device list:
  #0: Marvell mv88fx_snd ALSA driver
TCP cubic registered
NET: Registered protocol family 1
NET: Registered protocol family 17
eth0: link down
eth0: started
IP-Config: Guessing netmask 255.255.255.0
IP-Config: Complete:
      device=eth0, addr=192.168.2.89, mask=255.255.255.0, gw=255.255.255.255,
     host=DB88FXX81, domain=, nis-domain=(none),
     bootserver=192.168.2.38, rootserver=192.168.2.38, rootpath=
md: Autodetecting RAID arrays.
md: autorun ...
md: ... autorun DONE.
Looking up port of RPC 100003/2 on 192.168.2.38
eth0: link up, full duplex, speed 1 Gbps
Looking up port of RPC 100005/1 on 192.168.2.38
VFS: Mounted root (nfs filesystem).
Freeing init memory: 104K
init started: BusyBox v1.7.0 (2008-02-26 19:25:17 IST)
starting pid 260, tty '': '/etc/init.d/rcS'
starting pid 262, tty '': '/bin/sh'
-sh-3.2#
できた。

flash のマウント

実はやりたかったのはこれ
-sh-3.2# ls /
bin      etc      linuxrc  mnt1     sbin
dev      lib      mnt      proc     usr
-sh-3.2# ls /mnt
-sh-3.2# mount -t jffs2 /dev/mtdblock1 /mnt
しばらくして
Empty flash at 0x0fcb49ac ends at 0x0fcb5000
-sh-3.2# df
Filesystem           1k-blocks      Used Available Use% Mounted on
/dev/mtdblock1          519168    152360    366808  29% /mnt
-sh-3.2# ls /mnt
bin      etc      media    proc     selinux  tmp
boot     home     mnt      root     srv      usr
dev      lib      opt      sbin     sys      var
-sh-3.2#
書けることも確認する。
-sh-3.2# echo a > /mnt/tmp/a
-sh-3.2# cat /mnt/tmp/a
a
-sh-3.2#
と言うことで、玄柴も NFS root でブート可能。 まぁ、あたりまえ。

bootargs を戻す

-sh-3.2# reboot
The system is going down NOW!
Sending SIGTERM to all processes
Requesting system reboot
md: stopping all md devices.
Restarting system.
Reseting !!

         __  __                      _ _
        |  \/  | __ _ _ ____   _____| | |
        | |\/| |/ _` | '__\ \ / / _ \ | |
        | |  | | (_| | |   \ V /  __/ | |
        |_|  |_|\__,_|_|    \_/ \___|_|_|
 _   _     ____              _
| | | |   | __ )  ___   ___ | |_
| | | |___|  _ \ / _ \ / _ \| __|
| |_| |___| |_) | (_) | (_) | |_
 \___/    |____/ \___/ \___/ \__|
 ** MARVELL BOARD: SHEEVA PLUG LE

U-Boot 1.1.4 (Sep  7 2009 - 20:21:09) Marvell version: 3.4.16

U-Boot code: 00600000 -> 0067FFF0  BSS: -> 006CEE60

Soc: 88F6281 A0 (DDR2)
CPU running @ 1200Mhz L2 running @ 400Mhz
SysClock = 400Mhz , TClock = 200Mhz

DRAM CAS Latency = 5 tRP = 5 tRAS = 18 tRCD=6
DRAM CS[0] base 0x00000000   size 256MB
DRAM CS[1] base 0x10000000   size 256MB
DRAM Total size 512MB  16bit width
Flash:  0 kB
Addresses 8M - 0M are saved for the U-Boot usage.
Mem malloc Initialization (8M - 7M): Done
NAND:512 MB

CPU : Marvell Feroceon (Rev 1)

Streaming disabled
Write allocate disabled


USB 0: host mode
PEX 0: interface detected no Link.
Net:   egiga0 [PRIME], egiga1
Hit any key to stop autoboot:  0
Marvell>> set bootargs console=ttyS0,115200 mtdparts=nand_mtd:0x400000@0x100000(uImage),0x1fb00000@0x500000(rootfs) rw root=/dev/mtdblock1 rw ip=10.4.50.4:10.4.50.5:10.4.50.5:255.255.255.0:DB88FXX81:eth0:none
Marvell>> saveenv
Saving Environment to NAND...
Erasing Nand...Writing to Nand... done
Marvell>>
KURO-SHEEVA
楽天市場
←（前のページ）
Ubuntu オフラインミーティング Kansai 10.10 で「SheevaPlug/玄柴をハックしよう」 #ubuntujp 		当月のハックの記録
SheevaPlug/玄柴(KURO-SHEEVA)をハックしよう　トップ 		（次のページ）→
NFS root でバックアップ
Copyright (C) 2003-2011 Yasunari Yamashita. All Rights Reserved.
yasunari ＠ yamasita.jp　山下康成＠京都府向日市
